TT-2525RI
TT typeInternal threading toolholders, Pin lock
| Shank Height (H) | 25 mm | Tool Type | Internal Indexable Threading Tools |
| Shank Width (B) | 25 mm | Head Length (LH) | 70 mm |
| Minimum Bore Diameter (DMIN) | 50 mm | Body Material | Steel |
| Overall Length (OAL) | 200 mm | Measurement Type | Metric |
| Cutting Direction (HAND) | Right Hand | Unit | M |
| Application | | Ext Threading | Internal Threading | |
Product Features
| Family Description | TT typeInternal threading toolholders, Pin lock | FamilyName | TT-RI |
| Remarks | Notes : The left hand insert is used for right hand toolholders. | BrandName | Tungaloy |
| COO | JAPAN |
Shipping Info
Weight per item
0.9940
Name
On-Edge Threading Indexable Holders
FamilyName
TT-RI
BrandName
Tungaloy
