C5 ASHR 20-45
TungCap Adapter for Square Shank Toolholders with 45 deg slanted
| Connection Diameter Machine Side (DCONMS) | 50 mm | Application | | Face contact interface | |
| Shank Width (B) | 20 mm | Cutting Direction (HAND) | Right Hand |
| Shank Height (H) | 20 mm | Tool Type | ISO 26623-1 (CAMFIX, CAPTO) |
| Body Diameter (BD) | 72 mm | Measurement Type | Metric |
| Functional Width (WF) | 15 mm | Body Material | Steel |
| Shank Size (SS) | C5 | Unit | M |
Product Features
| Family Description | TungCap Adapter for Square Shank Toolholders with 45 deg slanted | FamilyName | C-ASHR/L-45 |
| Remarks | Regular shank should be shortened. Applicable for 7 MPa coolant | BrandName | Tungaloy |
| COO | ISRAEL |
Shipping Info
Weight per item
1.7920
Name
Adapters
FamilyName
C-ASHR/L-45
BrandName
Tungaloy
