VST177W3.00R020-3S06 AH735
Slotting, 3, 4, 6 flutes, for slotting
| Application | | Slot Milling | | Flute Helix Angle (FHA) | 0 Degrees |
| Cutting Diameter (DC) | 17.7 mm | Grade | AH735 |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Super-Alloys / Titanium | | Coating | TiAlSiCrN |
| Flute Count (NOF) | 3 | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Corner Radius (RE) | 0.2 mm | Measurement Type | Metric |
| Cutting Diameter Maximum (DCX) | 17.7 mm | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 3 mm | Tool Type | Solid "T" slot cutters |
| Cutting Width (CW) | 3 mm | Body Material | Carbide |
| Functional Length (LF) | 3.15 mm | Unit | M |
Product Features
| Family Description | Slotting, 3, 4, 6 flutes, for slotting | FamilyName | VST-3,4,6 |
| Remarks | Torque: Recommended torque (Nm) for clamping. | BrandName | Tungaloy |
| COO | JAPAN |
Shipping Info
Weight per item
0.0000
Name
Solid End Mill Heads
FamilyName
VST-3,4,6
BrandName
Tungaloy
