VST217L01.70A45-4S08 GH730
Slotting, 3, 4 flutes, for slotting with 45 degree chamfer
| Application | | Multi Functional tools | | Grade | GH730 |
| Cutting Diameter (DC) | 21.7 mm | Coating | TiCNO |
| Applicable Material | | Steel | Stainless Steel | | Tool Cutting Edge Angle (KAPR) | 45 Degrees |
| Flute Count (NOF) | 4 | Measurement Type | Metric |
| Cutting Diameter Maximum (DCX) | 21.7 mm | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 5.5 mm | Tool Type | Solid "T" slot cutters |
| Cutting Width (CW) | 5.5 mm | Body Material | Carbide |
| Functional Length (LF) | 3.49 mm | Unit | M |
| Flute Helix Angle (FHA) | 0 Degrees |
Product Features
| Family Description | Slotting, 3, 4 flutes, for slotting with 45 degree chamfer | FamilyName | VST-A45 |
| Remarks | Torque: Recommended torque (Nm) for clamping. | BrandName | Tungaloy |
| COO | ISRAEL |
Shipping Info
Weight per item
0.0000
Name
Solid End Mill Heads
FamilyName
VST-A45
BrandName
Tungaloy
